Deskripsi

GW Instek GDM-8342 50000 counts Dual Measurement Multimeter with USB Host/Device and GPIB
============================================================
Features
• 50,000 counts, VFD display
• Dual measurement/Dual display
• Selectable measurement speeds, the maximum: 40 Readings/s for DCV
• The basic precision of DC voltage: 0.02%
• Auto/manual Ranging
• True RMS (AC,AC+DC) measurements
• 11 different measurement functions
• Max./Min., REL, MX+B, 1/X, Ref%, Compare, Hold, dB, dBm
• Standard USB device interface to connect with a computer
• Temperature measurement function
• USB storage for Data collection
============================================================
Specifications
DC VOLTAGE
-Range : 500mV – 1000V
-Resolution : 10µV – 100mV
RESISTANCE
-Range : 500Ω - 50MΩ
-Resolution : 10mΩ - 1kΩ
DC CURRENT
-Range : 500µA – 10A
-Resolution : 10nA – 1mA
CONTINUITY
-Range : 500Ω
-Resolution : 100mΩ
DIODE TEST
-Range : 5V
-Resolution : 100µV
CAPACITANCE
-Range : 5nF - 50µF
-Resolution : 0.001nF – 10nF
FREQUENCY : 10Hz – 1MHz
TRUE RMS AC (or AC+DC – AC Coupled) VOLTAGE
-Range : 500mV – 750V
-Resolution : 10µV – 100mV
TRUE RMS AC (or AC+DC – AC Coupled) CURRENT
-Range : 500µA – 10A
-Resolution : 10nA – 1mA
THERMOCOUPLE TEMPERATURE : -200°C - 300°C (J/T/K)
INTERFACE : USB device, USB Host
DISPLAY : VFD, Two Colors Display
POWER SOURCE : AC 100V/120V/220V/240V ±10%, 50-60Hz, Max. 15VA
DIMENSIONS & WEIGHT : 265(W) x 107(H) x 302(D)mm, Approx. 2.9kg
ACCESSORIES : Safety Instruction Sheet x 1, Power cord x 1, Test lead GTL-207A x 1, CD x 1 (including complete user manual, USB driver and PC software)
===========================================================
UNTUK MENGHINDARI PESANAN BARANG ANDA DITOLAK OLEH KAMI, SILAHKAN BERTANYA STOCK BARANG TERLEBIH DAHULU. TERIMA KASIH
Untuk informasi dan pemesanan, silahkan menghubungi :
Telp. & WA : 62.813.3117.0440
Mail : asiaindustri@gmail.com
============================================================

Lihat selengkapnya

GW Instek GDM-8342 50000 counts Dual Measurement Multimeter with USB Host/Device and GPIB

Rp 11.962.000
